FastPass Series Stainless Waist High Turnstile

FastPass Series Tripod waist high turnstile

FP500 TRIPOD

FP500-P PORTABLE

FP500-ADA

FP500-C COIN

View Turnstile Options

The FastPass™ Series waist high turnstile units are high traffic volume units crafted in 304 stainless steel. They’re in service worldwide at pro stadiums and arenas, health clubs, universities and public venues, and are ideal for situations where you want reliable performance and the beauty and durability of stainless steel. FastPass units can be equipped with LCD counters, computer attendance systems, card readers, push-buttons and wireless remotes and coin processors.

Portable (FP500-P) units are available, and feature a base plate, wheels for easy movement and a curved bar that creates a lane for passage. These are ideal where you want to move your turnstiles and are popular for convention centers and arenas. Customers frequently use these with our battery operated counters for a flexible traffic flow solution. An ADA-compliant, handicapped gate is also part of this series (FP500-ADA).

In addition, we offer a coin totaling FastPass unit (FP500-C) and a ticket stub extension (FP500-T).

View Photos

Turnstile Options

Dimensions & Drawings

FASTPASS SERIES TRIPOD

FastPass Waist High Turnstile Technical Drawing

Dimensions
HEIGHT	38.062″
WIDTH	23.218″
DEPTH*	27.437″
BASE	8.000″
ARM LENGTH	15.000″

*The FP500 unit’s standard depth is 27.437″. The FP500-C and FP500-T units have a depth of 33.437”.

FASTPASS SERIES PORTABLE

FastPass Portable Turnstile Technical Drawing

Dimensions
HEIGHT	38.062″
WIDTH	32.450″
DEPTH	27.437″
BASE	28.000″
ARM LENGTH	15.000″

FASTPASS SERIES ADA

FastPass Waist High ADA Turnstile Technical Drawing

Dimensions
HEIGHT	38.062″
WIDTH	47.000″
DEPTH	27.437″
BASE	8.000″
PASSAGE	36.000″

Options

FP500 Tripod:

Bidirectional key overrides
Daylight visible indicator lights
8 digit key resettable digital counter with LCD display and 7-year lithium battery
12 Ah 24 VDC battery backup system
Single coin/token acceptor
Multiple coin totalizer
Bill acceptor
Ticket stub drop box

FP500-P (Portable):

Bidirectional key overrides
8 digit key resettable digital counter with LCD display and 7-year lithium battery
Ticket stub drop box

FP500-ADA Swing Gate:

Bidirectional key overrides (fail open only)
Daylight visible indicator lights
8 digit key resettable digital counter with LCD display and 7-year lithium battery
12 Ah 24 VDC battery backup system
ADA push to exit placard button
Signage bracketry
Variable arm lengths (up to 40″)
Variable speed self-opening motorized arm (FP500-ADA-M) with safety clutch to prevent injury
Single coin/token acceptor
Multiple coin totalizer
Bill acceptor
Ticket stub drop box

Additional options are available upon request.

Technical Documents

The following technical documents are available as downloadable PDF documents. If you have any issues with them or need additional information, please contact us.

Data Sheet & Installation Guide:

Assembly Drawings:

Anchor & Conduit Locations:

Does your equipment seem a little different than shown in the above documents? Please check out our Obsolete Resources page to review electrical and mechanical information on older versions of our equipment.

6500 Series Control Head

Every turnstile we build operates with our durable 6500 Series Control Head. This flexible, easy-to-service modular control system allows for our units to be configured to meet your unique security needs.

Factory configurations include:

Manual (free passage) in both directions
Manual (free passage) in one direction, locked in the other direction
Electronically controlled in one direction, manual (free passage) in the other direction
Electronically controlled in one direction, locked in the other direction
Electronically controlled in both directions

Electronic control heads can also be configured to be fail-lock(secure), fail-open(safe) or any combination of the two for no additional charge.

A key-override option is also available to give you the ability to unlock your turnstile with a simple key turn.

The 6500 Series Control Head is certified by Intertek to conform to the following standards: UL 294, UL 325, UL Subject 2593, CAN/ULC S319 and CSA C22.2#247.

Learn More

Additional Suggestions

Coin mechanism units (FP500-C) offer a choice of either single or multi-coin/multi-token totaling capability.

For ticket stub collection, we offer the (FP500-T), a cabinet extension with ticket collection component.
